Banjo Polypropylene Manifold Fittings
Showing 1–16 of 99 results
Category Products
-
90° Flanged Couplings (4)
-
Banjo Electric 5 Way Ball Valve (1)
-
Banjo Flow Meters (7)
-
Flange Clamps (4)
-
Flange Gaskets (8)
-
Flange Plugs (4)
-
Flange Plugs with Gauge Ports (6)
-
Flange Swivels (1)
-
Flange x 45° Hose Barb (1)
-
Flange x 90° Hose Barb (11)
-
Flange x BSP Male Thread (4)
-
Flange x Cam Lever Adaptors (4)
-
Flange x Female Thread (6)
-
Flange x Hose Barb (12)
-
Flange x Male Thread (8)
-
Flanged Couplings (5)
-
Flanged Crosses (4)
-
Flanged Reducer Couplings (5)
-
Flanged Tees (4)
General Products
90° Flanged Coupling
- 1" flanges
- 10 Bar max pressure @ 21°C
- -17 to 65°C working temperature
- Glass reinforced polypropylene
Quick View- 1″ flanges
- 10 Bar max pressure @ 21°C
- -17 to 65°C working temperature
- Glass reinforced polypropylene
90° Flanged Coupling
- 2" flanges
- 10 Bar max pressure @ 21°C
- -17 to 65°C working temperature
- Glass reinforced polypropylene
Quick View- 2″ flanges
- 10 Bar max pressure @ 21°C
- -17 to 65°C working temperature
- Glass reinforced polypropylene
90° Flanged Coupling
- 2" full port flanges
- 10 Bar max pressure @ 21°C
- -17 to 65°C working temperature
- Glass reinforced polypropylene
Quick View- 2″ full port flanges
- 10 Bar max pressure @ 21°C
- -17 to 65°C working temperature
- Glass reinforced polypropylene
90° Flanged Coupling
- 3" flanges
- 8.6 Bar max pressure @ 21°C
- -17 to 65°C working temperature
- Glass reinforced polypropylene
Quick View- 3″ flanges
- 8.6 Bar max pressure @ 21°C
- -17 to 65°C working temperature
- Glass reinforced polypropylene
Banjo Cam Lever Gasket
- VITON (green band)
- For 1"1/4 & 1"1/2 couplings
- For 2" manifold fittings
Quick View- VITON (green band)
- For 1″1/4 & 1″1/2 couplings
- For 2″ manifold fittings
Banjo Cam Lever Gasket
- VITON (green band)
- For 2" couplings
- For 2"FP manifold fittings
Quick View- VITON (green band)
- For 2″ couplings
- For 2″FP manifold fittings
Banjo Cam Lever Gasket
- VITON (green band)
- For 3" couplings
- For 3" manifold fittings
Quick View- VITON (green band)
- For 3″ couplings
- For 3″ manifold fittings
Banjo Electric 5 Way Directional Valve
- 2" flanges
- 2" ball i.d. - Full port
- 12 Volt DC - 3 Amp - 3 Wire
- 3 second cycle
- 10 Bar max pressure @ 21°C
- Reinforced polypropylene body
- AISI316 stainless steel ball & stem
- PTFE seats - Viton seals
- Internally fused/auto reset
- Directional flow cannot be turned off
Quick View- 2″ flanges
- 2″ ball i.d. – Full port
- 12 Volt DC – 3 Amp – 3 Wire
- 3 second cycle
- 10 Bar max pressure @ 21°C
- Reinforced polypropylene body
- AISI316 stainless steel ball & stem
- PTFE seats – Viton seals
- Internally fused/auto reset
- Directional flow cannot be turned off
Banjo Flow Meter – Battery Powered
- 1" female thread ports
- 1" full port flow
- 10.3 Bar max pressure
- 8 to 416 Lpm working flow
- Accurate to +/- 1%
- Powered by 6x AA batteries
- -17° to 65°C working temperature
- Self calibrating magnetic meter
- 6/8 digit digital display
- Reads flow rate & totals (USGPM or LPM)
- See user manual for installation instructions
Quick View- 1″ female thread ports
- 1″ full port flow
- 10.3 Bar max pressure
- 8 to 416 Lpm working flow
- Accurate to +/- 1%
- Powered by 6x AA batteries
- -17° to 65°C working temperature
- Self calibrating magnetic meter
- 6/8 digit digital display
- Reads flow rate & totals (USGPM or LPM)
- See user manual for installation instructions
Banjo Flow Meter – Battery Powered
- 1" flange ports
- 1" full port flow
- 10.3 Bar max pressure
- 8 to 416 Lpm working flow
- Accurate to +/- 1%
- Powered by 6x AA batteries
- -17° to 65°C working temperature
- Self calibrating magnetic meter
- 6/8 digit digital display
- Reads flow rate & totals (USGPM or LPM)
- See user manual for installation instructions
Quick View- 1″ flange ports
- 1″ full port flow
- 10.3 Bar max pressure
- 8 to 416 Lpm working flow
- Accurate to +/- 1%
- Powered by 6x AA batteries
- -17° to 65°C working temperature
- Self calibrating magnetic meter
- 6/8 digit digital display
- Reads flow rate & totals (USGPM or LPM)
- See user manual for installation instructions
Banjo Flow Meter – Battery Powered
- 2" flange ports
- 2" full port flow
- 10.3 Bar max pressure
- 23 to 1135 Lpm working flow
- Accurate to +/- 1%
- Powered by 6x AA batteries
- -17° to 65°C working temperature
- Self calibrating magnetic meter
- 6/8 digit digital display
- Reads flow rate & totals (USGPM or LPM)
- See user manual for installation instructions
Quick View- 2″ flange ports
- 2″ full port flow
- 10.3 Bar max pressure
- 23 to 1135 Lpm working flow
- Accurate to +/- 1%
- Powered by 6x AA batteries
- -17° to 65°C working temperature
- Self calibrating magnetic meter
- 6/8 digit digital display
- Reads flow rate & totals (USGPM or LPM)
- See user manual for installation instructions
Banjo Flow Meter – Battery Powered
- 3" flange ports
- 3" full port flow
- 10.3 Bar max pressure
- 53 to 2536 Lpm working flow
- Accurate to +/- 1%
- Powered by 6x AA batteries
- -17° to 65°C working temperature
- Self calibrating magnetic meter
- 6/8 digit digital display
- Reads flow rate & totals (USGPM or LPM)
- See user manual for installation instructions
Quick View- 3″ flange ports
- 3″ full port flow
- 10.3 Bar max pressure
- 53 to 2536 Lpm working flow
- Accurate to +/- 1%
- Powered by 6x AA batteries
- -17° to 65°C working temperature
- Self calibrating magnetic meter
- 6/8 digit digital display
- Reads flow rate & totals (USGPM or LPM)
- See user manual for installation instructions
Banjo Flow Meter – External Power
- 1" flange ports
- 1" full port flow
- 10.3 Bar max pressure
- 8 to 416 Lpm working flow
- Accurate to +/- 1%
- 10 to 30 Vdc - Needs external power supply
- -17° to 65°C working temperature
- Self calibrating magnetic meter
- 6/8 digit digital display
- Reads flow rate & totals (USGPM or LPM)
- See user manual for installation instructions
Quick View- 1″ flange ports
- 1″ full port flow
- 10.3 Bar max pressure
- 8 to 416 Lpm working flow
- Accurate to +/- 1%
- 10 to 30 Vdc – Needs external power supply
- -17° to 65°C working temperature
- Self calibrating magnetic meter
- 6/8 digit digital display
- Reads flow rate & totals (USGPM or LPM)
- See user manual for installation instructions
Banjo Flow Meter – External Power
- 2" flange ports
- 2" full port flow
- 10.3 Bar max pressure
- 23 to 1135 Lpm working flow
- Accurate to +/- 1%
- 10 to 30 Vdc - Needs external power supply
- -17° to 65°C working temperature
- Self calibrating magnetic meter
- 6/8 digit digital display
- Reads flow rate & totals (USGPM or LPM)
- See user manual for installation instructions
Quick View- 2″ flange ports
- 2″ full port flow
- 10.3 Bar max pressure
- 23 to 1135 Lpm working flow
- Accurate to +/- 1%
- 10 to 30 Vdc – Needs external power supply
- -17° to 65°C working temperature
- Self calibrating magnetic meter
- 6/8 digit digital display
- Reads flow rate & totals (USGPM or LPM)
- See user manual for installation instructions
Banjo Flow Meter – External Power
- 3" flange ports
- 3" full port flow
- 10.3 Bar max pressure
- 53 to 2536 Lpm working flow
- Accurate to +/- 1%
- 10 to 30 Vdc - Needs external power supply
- -17° to 65°C working temperature
- Self calibrating magnetic meter
- 6/8 digit digital display
- Reads flow rate & totals (USGPM or LPM)
- See user manual for installation instructions
Quick View- 3″ flange ports
- 3″ full port flow
- 10.3 Bar max pressure
- 53 to 2536 Lpm working flow
- Accurate to +/- 1%
- 10 to 30 Vdc – Needs external power supply
- -17° to 65°C working temperature
- Self calibrating magnetic meter
- 6/8 digit digital display
- Reads flow rate & totals (USGPM or LPM)
- See user manual for installation instructions
Flange Clamp
- 1" clamp
- 100 series worm screw clamp
- 70-80 in/lbs max torque
- 300 series stainless steel
Quick View- 1″ clamp
- 100 series worm screw clamp
- 70-80 in/lbs max torque
- 300 series stainless steel
